Key Specs

  • Horizontal Outreach: 20 ft 2 in. / 6.15 m
  • Platform Capacity: 500 lb / 226.80 kg
  • Platform Height: 34 ft 5 in. / 10.49 m

Key Features

  • Gasoline engine or 24V DC electric power
  • Standard air and water lines to platform
  • Accessory Mounting Tray accommodates your generator, air compressor or pressure washer

Features

  • Gasoline engine or 24V DC electric power

  • Standard air and water lines to platform

  • Accessory Mounting Tray accommodates your generator, air compressor or pressure washer

Specifications

Batteries:
4 x 6V 220 amp-hr
Capacity - Hydraulic Reservoir:
4 gal. / 15.14 L
Ground Clearance:
1 ft 2 in. / 0.36 m
Ground Entry Height:
10 in. / 0.25 m
Horizontal Outreach:
20 ft 2 in. / 6.15 m
Jib - Range of articulation:
0 Degrees
Leveling Capability:
11 Degrees
Machine Height:
6 ft 6 in. / 1.98 m
Machine Length:
21 ft 9 in. / 6.63 m
Machine Weight:
3400 lb / 1542.21 kg
Machine Width:
4 ft 9 in. / 1.45 m
Maximum Ground Bearing Pressure:
23 psi / 1.61 Kg/cm2
Outrigger Footprint Length:
11 ft 7 in. / 3.53 m
Outrigger Footprint Width:
10 ft 5 in. / 3.18 m
Outriggers or Stabilizers:
Yes
Platform Capacity:
500 lb / 226.80 kg
Platform Dimension A:
2 ft 6 in. / 0.76 m
Platform Dimension B:
4 ft / 1.22 m
Platform Height:
34 ft 5 in. / 10.49 m
Swing:
410 Degrees
Swing Type:
Non-Continuous
Tire Size:
205/75 R14 Pnuematic
Towing Speed Rating:
65 mph / 104.61 km/h
Up and Over Height:
15 ft / 4.57 m
  • Features

    Features

    • Gasoline engine or 24V DC electric power

    • Standard air and water lines to platform

    • Accessory Mounting Tray accommodates your generator, air compressor or pressure washer

  • Specifications

    Specifications

    Batteries:
    4 x 6V 220 amp-hr
    Capacity - Hydraulic Reservoir:
    4 gal. / 15.14 L
    Ground Clearance:
    1 ft 2 in. / 0.36 m
    Ground Entry Height:
    10 in. / 0.25 m
    Horizontal Outreach:
    20 ft 2 in. / 6.15 m
    Jib - Range of articulation:
    0 Degrees
    Leveling Capability:
    11 Degrees
    Machine Height:
    6 ft 6 in. / 1.98 m
    Machine Length:
    21 ft 9 in. / 6.63 m
    Machine Weight:
    3400 lb / 1542.21 kg
    Machine Width:
    4 ft 9 in. / 1.45 m
    Maximum Ground Bearing Pressure:
    23 psi / 1.61 Kg/cm2
    Outrigger Footprint Length:
    11 ft 7 in. / 3.53 m
    Outrigger Footprint Width:
    10 ft 5 in. / 3.18 m
    Outriggers or Stabilizers:
    Yes
    Platform Capacity:
    500 lb / 226.80 kg
    Platform Dimension A:
    2 ft 6 in. / 0.76 m
    Platform Dimension B:
    4 ft / 1.22 m
    Platform Height:
    34 ft 5 in. / 10.49 m
    Swing:
    410 Degrees
    Swing Type:
    Non-Continuous
    Tire Size:
    205/75 R14 Pnuematic
    Towing Speed Rating:
    65 mph / 104.61 km/h
    Up and Over Height:
    15 ft / 4.57 m
