Key Specs

  • Platform Height: 33 ft 10 in. / 10.31 m
  • Platform Capacity - Unrestricted: 500 lb / 226.80 kg
  • Horizontal Outreach: 19 ft 11 in. / 6.07 m

Key Features

  • Lower cost of ownership
  • Steel hoods provide added durability
  • Environmentally-friendly Tier 4 diesel engine
  • Industry-leading terrainability
  • Ideal for general contractors, steel erectors, painters, stadium construction and more

Features

  • Environmentally-friendly Tier 4 diesel engine

  • Lower cost of ownership

  • Steel hoods provide added durability

  • Industry-leading terrainability

  • Ideal for general contractors, steel erectors, painters, stadium construction and more

Specifications

Auxiliary Power:
12 Volts DC
Axle Oscillation:
6 in. / 0.15 m
Capacity - Fuel Tank:
13 gal. / 49.21 L
Capacity - Hydraulic Reservoir:
20.6 gal. / 77.98 L
Drive Speed - 4WD:
3.1 mph / 4.99 km/h
Engine Type - Diesel:
Kubota D1105 24.8 hp
Engine Type - Dual Fuel:
PSI/GM 28.7 hp
Gradeability - 4WD:
45 %
Ground Clearance:
10 in. / 0.25 m
Horizontal Jib Rotation:
0 Degrees
Horizontal Outreach:
19 ft 11 in. / 6.07 m
Jib - Range of articulation:
144 Degrees
Machine Height:
6 ft 7 in. / 2.01 m
Machine Length:
18 ft 2 in. / 5.54 m
Machine Weight:
9700 lb / 4399.85 kg
Machine Width:
6 ft 4 in. / 1.93 m
Maximum Ground Bearing Pressure:
151 psi / 10.57 Kg/cm2
Platform Capacity - Unrestricted:
500 lb / 226.80 kg
Platform Dimension A:
2 ft 6 in. / 0.76 m
Platform Height:
33 ft 10 in. / 10.31 m
Swing:
355 Degrees
Swing Type:
Non-Continuous
Tailswing:
2 in. / 0.05 m
Tire Size:
265/50020 Lug Tread
Turning Radius - Outside:
5 ft / 1.52 m
Up and Over Height:
17 ft / 5.18 m
  • Features

    Features

    • Environmentally-friendly Tier 4 diesel engine

    • Lower cost of ownership

    • Steel hoods provide added durability

    • Industry-leading terrainability

    • Ideal for general contractors, steel erectors, painters, stadium construction and more

  • Specifications

    Specifications

    Auxiliary Power:
    12 Volts DC
    Axle Oscillation:
    6 in. / 0.15 m
    Capacity - Fuel Tank:
    13 gal. / 49.21 L
    Capacity - Hydraulic Reservoir:
    20.6 gal. / 77.98 L
    Drive Speed - 4WD:
    3.1 mph / 4.99 km/h
    Engine Type - Diesel:
    Kubota D1105 24.8 hp
    Engine Type - Dual Fuel:
    PSI/GM 28.7 hp
    Gradeability - 4WD:
    45 %
    Ground Clearance:
    10 in. / 0.25 m
    Horizontal Jib Rotation:
    0 Degrees
    Horizontal Outreach:
    19 ft 11 in. / 6.07 m
    Jib - Range of articulation:
    144 Degrees
    Machine Height:
    6 ft 7 in. / 2.01 m
    Machine Length:
    18 ft 2 in. / 5.54 m
    Machine Weight:
    9700 lb / 4399.85 kg
    Machine Width:
    6 ft 4 in. / 1.93 m
    Maximum Ground Bearing Pressure:
    151 psi / 10.57 Kg/cm2
    Platform Capacity - Unrestricted:
    500 lb / 226.80 kg
    Platform Dimension A:
    2 ft 6 in. / 0.76 m
    Platform Height:
    33 ft 10 in. / 10.31 m
    Swing:
    355 Degrees
    Swing Type:
    Non-Continuous
    Tailswing:
    2 in. / 0.05 m
    Tire Size:
    265/50020 Lug Tread
    Turning Radius - Outside:
    5 ft / 1.52 m
    Up and Over Height:
    17 ft / 5.18 m
