Key Specs

  • Platform Height: 86 ft / 26.21 m
  • Platform Capacity - Restricted: 750 lb / 340.19 kg
  • Platform Capacity - Unrestricted: 500 lb / 226.80 kg
  • Horizontal Outreach: 75 ft / 22.86 m

Key Features

  • Reach full elevation in less than 70 seconds
  • Advanced Design Electronics System reduces your costs by increasing fuel efficiency and reducing emissions
  • Equipped with a fuel-efficient Tier 4 engine

Features

  • Equipped with a fuel-efficient Tier 4 engine

  • Reach full elevation in less than 70 seconds

  • Advanced Design Electronics System reduces your costs by increasing fuel efficiency and reducing emissions

Specifications

Auxiliary Power:
12 Volts DC
Axle Oscillation:
8 in. / 0.2 m
Capacity - Fuel Tank:
31 gal. / 117.35 L
Capacity - Hydraulic Reservoir:
48 gal. / 181.70 L
Drive Speed - 4WD:
3.5 mph / 5.63 km/h
Engine Type - Diesel:
DEUTZ TD 2.9L Tier 4 Final 67 hp
Engine Type - Dual Fuel:
Ford MSG425 84hp
Gradeability - 2WD:
25 %
Gradeability - 4WD:
45 %
Ground Clearance:
11 in. / 0.28 m
Horizontal Jib Rotation:
0 Degrees
Horizontal Outreach:
75 ft / 22.86 m
Jib - Range of articulation:
130 Degrees
Machine Height:
10 ft / 3.05 m
Machine Length:
40 ft / 12.19 m
Machine Weight:
36230 lb / 16433.65 kg
Machine Width:
8 ft 2 in. / 2.49 m
Maximum Ground Bearing Pressure:
81 psi / 5.67 Kg/cm2
Platform Capacity - Restricted:
750 lb / 340.19 kg
Platform Capacity - Unrestricted:
500 lb / 226.80 kg
Platform Dimension A:
3 ft / 0.91 m
Platform Dimension B:
8 ft / 2.44 m
Platform Height:
86 ft / 26.21 m
Swing:
360 Degrees
Swing Type:
Continuous
Tailswing:
4 ft 8 in. / 1.42 m
Tire Size:
15-625 Pnuematic
Turning Radius - Outside:
19 ft 8 in. / 5.99 m
