Key Specs

  • Maximum Lift Capacity: 9000 lb / 4082.33 kg
  • Maximum Lift Height: 43 ft / 13.11 m
  • Maximum Reach: 30 ft 5 in. / 9.27 m

Key Features

  • Enhanced operator comfort—spacious cab, intuitive single joystick and integrated arm rest
  • Maximum serviceability— extended service intervals, easy-to-access parts and durable components for less overall maintenance
  • Greater operator confidence— better visibility, Stabil-Trak rear axle stabilization, precision gravity lowering system, optional reverse sensing system and reversing camera
  • Optional 74 hp engine doesn’t require Diesel Exhaust Fluid (DEF) and meets Tier 4 Final regulations
  • Increased versatility—wide range of attachment options

Features

  • Greater operator confidence— better visibility, Stabil-Trak rear axle stabilization, precision gravity lowering system, optional reverse sensing system and reversing camera

  • Maximum serviceability— extended service intervals, easy-to-access parts and durable components for less overall maintenance

  • Increased versatility—wide range of attachment options

  • Optional 74 hp engine doesn’t require Diesel Exhaust Fluid (DEF) and meets Tier 4 Final regulations

  • Enhanced operator comfort—spacious cab, intuitive single joystick and integrated arm rest

Specifications

Axle-Front:
High Bias, Limited Slip
Axle-Rear:
Planetary
Capacity - Fuel Tank:
38.3 gal. / 144.98 L
Drawbar Pull:
22751 lb / 10319.68 kg
Engine Horsepower:
110 hp / 82.06 kW
Engine Manufacturer:
Cummins
Engine Model:
QSF3.8L Tier 4 Final
Frame Leveling:
10 Degrees
Function Pump Type:
Load Sensing Piston
Ground Clearance:
1 ft 5 in. / 0.43 m
Lift Capacity at Full Height:
7000 lb / 3175.15 kg
Lift Capacity at Max Reach:
1200 lb / 544.31 kg
Load Center:
2 ft / 0.61 m
Machine Height:
8 ft 2 in. / 2.49 m
Machine Length:
19 ft 9 in. / 6.02 m
Machine Width:
8 ft 1 in. / 2.46 m
Maximum Engine RPM:
1500 rpm
Maximum Lift Capacity:
9000 lb / 4082.33 kg
Maximum Lift Height:
43 ft / 13.11 m
Maximum Reach:
30 ft 5 in. / 9.27 m
Operating Vehicle Weight:
24912 lb / 11299.89 kg
Outriggers or Stabilizers:
No
Outside Turning Radius:
12 ft / 3.66 m
Service Brake Type:
Wet Multi-Disc
Speed - Maximum Lift:
13 sec.
Speed - Maximum Lower:
9 sec.
Speed - Maximum Telescope Out:
15 sec.
Speed - Maximum Travel:
19 mph / 30.58 km/h
Tire Size:
370/75-28
Transmission - Nr Forward Gears Standard:
4
Transmission - Nr Reverse Gears:
3
Transmission Type:
Powershift
Wheelbase:
11 ft 3 in. / 3.43 m
  • Features

    Features

    • Greater operator confidence— better visibility, Stabil-Trak rear axle stabilization, precision gravity lowering system, optional reverse sensing system and reversing camera

    • Maximum serviceability— extended service intervals, easy-to-access parts and durable components for less overall maintenance

    • Increased versatility—wide range of attachment options

    • Optional 74 hp engine doesn’t require Diesel Exhaust Fluid (DEF) and meets Tier 4 Final regulations

    • Enhanced operator comfort—spacious cab, intuitive single joystick and integrated arm rest

  • Specifications

    Specifications

    Axle-Front:
    High Bias, Limited Slip
    Axle-Rear:
    Planetary
    Capacity - Fuel Tank:
    38.3 gal. / 144.98 L
    Drawbar Pull:
    22751 lb / 10319.68 kg
    Engine Horsepower:
    110 hp / 82.06 kW
    Engine Manufacturer:
    Cummins
    Engine Model:
    QSF3.8L Tier 4 Final
    Frame Leveling:
    10 Degrees
    Function Pump Type:
    Load Sensing Piston
    Ground Clearance:
    1 ft 5 in. / 0.43 m
    Lift Capacity at Full Height:
    7000 lb / 3175.15 kg
    Lift Capacity at Max Reach:
    1200 lb / 544.31 kg
    Load Center:
    2 ft / 0.61 m
    Machine Height:
    8 ft 2 in. / 2.49 m
    Machine Length:
    19 ft 9 in. / 6.02 m
    Machine Width:
    8 ft 1 in. / 2.46 m
    Maximum Engine RPM:
    1500 rpm
    Maximum Lift Capacity:
    9000 lb / 4082.33 kg
    Maximum Lift Height:
    43 ft / 13.11 m
    Maximum Reach:
    30 ft 5 in. / 9.27 m
    Operating Vehicle Weight:
    24912 lb / 11299.89 kg
    Outriggers or Stabilizers:
    No
    Outside Turning Radius:
    12 ft / 3.66 m
    Service Brake Type:
    Wet Multi-Disc
    Speed - Maximum Lift:
    13 sec.
    Speed - Maximum Lower:
    9 sec.
    Speed - Maximum Telescope Out:
    15 sec.
    Speed - Maximum Travel:
    19 mph / 30.58 km/h
    Tire Size:
    370/75-28
    Transmission - Nr Forward Gears Standard:
    4
    Transmission - Nr Reverse Gears:
    3
    Transmission Type:
    Powershift
    Wheelbase:
    11 ft 3 in. / 3.43 m
