SJIII4740
Lifts - Scissor Lifts - Slab
Click photo to enlarge
Tap photo to enlarge
SKYJACK SJIII4740
Contact for Price
Lifts - Scissor Lifts - Slab
Need Sales Assistance?
(888) 503-4685
Equipment Specs
Contact for Price
-
General Information
- Classification: Machinery
- Year: 2020
- Make: SKYJACK
- Status: New
- Model: SJIII4740
- Availability: Available
-
General Description & Dealer Notes
Ready to ship, CALL DAVE TODAY OVERALL SPECIFICATIONS Work Height 45.3ʹ (13.8 m) Raised Platform Height 38.7ʹ (11.8 m) Lowered Platform Height 54" (1.37 m) Overall Width 47" (1.19 m) Overall Length 94.5" (2.40 m) Stowed Height (Rails Up) 97.5" (2.48 m) Stowed Height (Rails Down) 87.3� (2.21 m) Platform Width (Inside Dimension) 42" (1.06 m) Platform Length (Inside Dimension) 86" (2.19 m) Extension Deck (Roll Out) 3' (0.9 m) Ground Clearance (raised) 3.19" (8.1 cm) Wheelbase 73" (1.85 m) Weight 7480 lbs (3393 kg) Gradeability 25% Turning Radius (Inside) 21" (0.54 m) Turning Radius (Outside) 101" (2.58 m) Lift Time (With Rated Load) 71 sec Lower Time (With Rated Load) 41 sec Drive Speed (Stowed) 2.0 mph (3.2 km/h) Drive Speed (Raised) 0.62 mph (1.0 km/h) Maximum Drive Height Full Height Capacity (Overall) 500 lbs (227 kg) Maximum # of Persons 2 Wind Rating 28 mph (12.5 m/s) Tire Type Solid, N/M Tire Size 16 x 5 x 12
