Bobcat Bobcat S70 Skid-Steer Loader
| Make | Bobcat |
| Model | S70 (M2-Series) |
| Type | Skid Steer Loaders |
How can we help?
Description
The compact Bobcat® S70 skid-steer loader is small enough to get in the tight spots, yet tough enough to get you out. This agile little workhorse is only 6 ft. tall and 3 ft. wide — the ideal size for scooting through narrow doorways, corridors, aisles, alleys and gates, and for working under low ceilings. It's the perfect loader whenever the job is too big for a shovel or the space is too small for a larger machine.
Specifications
- Auxiliary High Flow : n/a
- Auxiliary Std Flow : 9.8 gal/min
- Emissions Tier (EPA) : Tier 4
- Engine Cooling : Liquid
- Engine Fuel : Diesel
- Fuel Tank : 6.5 gal
- Height : 71.4 in
- Height to Bucket Hinge Pin : 94.5 in
- Height with Operator Cab : 71.4 in
- Horsepower : 23.5 hp
- Length : 75.6 in
- Length with Standard Bucket : 97.3 in
- Length without Attachment : 75.6 in
- Operating Weight : 2892 lb
- Rated Operating Capacity (ISO) : 760 lb
- Reach @ Maximum Height : 15.8 in
- System Relief @ Quick Couplers : 3,000 psi
- Tipping Load : 1520 lb
- Travel Speed : 6.1 mph
- Turning Radius : 58.7 in
- Wheelbase : 28.4 in
- Width : 35.5 in
- Width (with bucket) : 36 in
Features
- Lift-Arm Support
- Auxiliary Hydraulics
- Adjustable Seat
- Horn
- Parking Brake
- Suspension Seat
- Rear Window
- Seat Belt
- Sound Option
- Operating Lights
- Bob-Tach Attachment System
- Cab Enclosure
- Developed more than 35 years ago, the standard Bob-Tach® mounting system is time-tested. With it, you can change attachments quickly and easily. Use a bucket, auger, landscape rake, grapple and other attachments throughout your day.
- Hydraulic Bucket Positioning
- Backup Alarm
- BICS System (Interlock)
- With two lift path options, Bobcat® skid-steer loaders have you covered. Vertical lift path machines provide more reach at full lift height, while radius lift path models offer maximum reach at truck bed height. The durable and patented single-plane design reduces side-to-side lift arm movement and minimizes load on the pins.
- Top Window
- Cab Heater
- Spark Arrestor Muffler
